86 Inch Meeting Room Multi Points Touch All In One Interactive Whiteboard
Product Details:
| Place of Origin: | Guangzhou,China |
| Brand Name: | KINDLO |
| Certification: | 3C,FCC,CE,GS,RoHS |
| Model Number: | KINDLO-JX1000EX-2K-WIN |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plastic packaging > foam > export standard carton |
| Delivery Time: | 7-15days（Negotiated） |
| Payment Terms: | T/T |
| Supply Ability: | 1500,pieces/week |
|
Detail Information |
|||
| Screen Type: | LG/Sumsung/ LED Module | Resolution: | 1920 * 1080 Or 3840 * 2160 |
|---|---|---|---|
| System: | Android And Windows | Touch Screen: | Infrared Touch |
| Total Color: | 16.7M (6-bit + Hi-FRC) | Refresh Frequency: | 60Hz |
| Contrast: | ≥ 5000: 1 | Working Temperature: | 0~45℃ |
| Lifetime: | > 60000 Hours | Touch Response Speed: | 8ms |
| High Light: | 86in All In One Interactive Whiteboard,Touchable All In One Interactive Whiteboard |
||
Product Description
86 Inch Meeting Room Multi Points Touch All In One Interactive Whiteboard
86 Inch Meeting Room Multi Points Touch All In One Interactive Whiteboard
KINDLO-JX1000EX-2K-WIN
Software functions:
| Product Model | KINDLO-JX1000EX-2K-WIN |
| LCD Panel | |
| Screen Size | 86 inch |
| Display area | 1872mm(H) X 1053mm(V) |
| Aspect Ratio | 16:09 |
| Pixel Pitch(mm) | 0.94(H)X0.94(V) |
| Max Resolution | 3840X2160 |
| Display color | 10Bit, 16.7M |
| Brightness (nits) | 350 cd/m2 |
| Contrast | 5000 : 1 |
| Viewing angle | 178°/178°/178°/178° |
| Response Time | 6ms |
| Screen Size | 86 inch |
| Touch screen parameter | |
| Touch style | Infrared Touch screen |
| Touch points | 10 points |
| Touch Max Resolution | 4096 X 4096 |
| Transparency | >90% ; Up to 100% |
| Scanning Speed | >50s scans/S |
| OPS PC BOX Configuration | |
| CPU | Intel I5 Processor, 4th Generation |
| RAM | 4GB |
| SSD | 128GB |
| Wifi | support |
| Rated load power | 135W |
| The dimension of OPS box | L196mmXW180mmXH33mm |
| Image resolution | Maxium support 3840*2160p@30Hz output |
| Operating System | Windows 10 system(English testing version) |
| Android PCB configuration | |
| CPU | Quad Core A73, 1.5GHz |
| RAM | 4GB |
| Built-in storage volume | 32GB |
| OS | Android 8.0 |
| Inner kernel | Linux 4.9 |
| Built-in HD camera module | |
| Pixel camera | 8 million pixels |
| Camera dual system following recognition | Includes built-in microphone, supports camera module to recognize after dual system switching |
| Pickup effective receiving range distance | ≤3 meters with high-sensitivity digital microphone |
| Onboard interface | |
| Input port | USB 3.0*2, USB 2.0*2, VGA IN*1, AUDIO IN*1, HDMI IN*3, Touch USB*1, Rs232*1 |
| Output port | VGA OUT*1, MIC*1, AV OUT*1, EAR PHONE*1, RF IN*1;SPDIF out*1;RJ45/LAN in out*1 |
| Power | |
| Power supply | AC 180-240V 50/60Hz |
| Maximum power consumption | ≤ 485W (the whole display with OPS PC) |
| Standby power consumption | < 0.5W |
| OSD display | |
| screen Menu language | Chinese/English |
Applicable places:
Financial institutions: banks, securities, funds, insurance companies, pawn shops, etc .;
Public places: bookstores, exhibition halls, stadiums, museums, conference centers, talent markets, etc .;
Industrial sites: food processing equipment, machinery control, office automation equipment, automated testing,
automotive testing equipment, etc .;
